�� Key Features ✅ High Efficiency (Up to 20.68%) – Mono PERC technology with a 9BB Half-Cell design ensures optimal energy conversion.✅ Increased Power Output – 9BB technology improves performance by reducing power loss.✅ Weatherproof & PID-Resistant – Certified against salt, ammonia, and extreme weather conditions.✅ Built for Durability – Withstands wind loads (2400 Pa) and snow loads (5400 Pa).✅ Long-Term Warranty – 12-year product warranty and 25-year linear power warranty.✅ Optimized Performance – Performs well even in low-light conditions for consistent power generation.✅ Easy Installation – MC4-compatible connectors and an IP67-rated junction box ensure safety and reliability. �� Technical Specifications ✔️ General Specifications Feature Specification Model Jinko 345W Mono PERC Half-Cell Cell Type Monocrystalline 5BB, 156.75mm x 156.75mm Cell Count 72 cells (6×12) Module Dimensions 1979mm × 1002mm × 40mm Front Glass 3.2mm High Transmission, Low Iron, Tempered ARC Glass Backsheet White TPT Frame Anodized Aluminium Alloy Junction Box IP67-rated, Potted with 3 Schottky bypass diodes Connector MC4 Compatible Cable Length 900mm Weight Approx. 23.5kg ✔️ Electrical Performance (STC Conditions) Feature Value Maximum Power (Pmax) 345W Max Power Voltage (Vmp) 40.5V Max Power Current (Imp) 9.39A Open Circuit Voltage (Voc) 48.9V Short Circuit Current (Isc) 9.75A Module Efficiency Up to 20.68% Power Output Tolerance 0 ~ 3W ✔️ Operating Conditions Feature Specification Operational Temperature -40°C to 85°C Maximum System Voltage 1500V DC Max Series Fuse Rating 20A �� Applications �� Residential & Commercial Solar Installations – Ideal for rooftop and ground-mounted systems.�� Off-Grid & Hybrid Solar Systems – Works for remote areas, backup power, and rural electrification.�� Solar Farms & Industrial Use – Suitable for large-scale solar energy projects.�� Harsh Weather Environments – Salt, ammonia, and extreme weather-resistant for durability.
