Description Canadian Solar 715W N-Type TOPCon Bifacial | TOPBiHiKu7 Series (CS7N-TB-AG) KEY FEATURES N-Type TOPCon Bifacial Technology: This module uses N-Type TOPCon cells with bifacial gain of up to 80% and superior performance even under high-temperature conditions. Ideal for installations aiming to maximize energy production. Robust and durable design: Structure with 2.0 mm tempered dual glass, anodized aluminum frame, and IP68 protection rating. Withstands loads up to 5400 Pa (snow) and 2400 Pa (wind). Excellent real-world performance: Temperature coefficient of just -0.29%/°C, low initial degradation (≤1%), and only 0.4% annual degradation over the following 29 years. Designed for large-scale projects: Its large format (2384 × 1303 × 33 mm) and high efficiency make it an optimal solution for solar parks, industrial rooftops, and agrivoltaic plants. TECHNICAL SPECIFICATIONS Electrical Data (STC): Nominal Power (Pmax): 710 W Voltage at MPP (Vmp): 40.6 V Current at MPP (Imp): 17.63 A Open Circuit Voltage (Voc): 48.5 V Short Circuit Current (Isc): 18.64 A Module Efficiency: 23.0% Bifacial Gain: up to 23% additional Mechanical Data: Cell Type: N-Type TOPCon Bifacial Cell Configuration: 132 (2 × 66) Dimensions: 2384 × 1303 × 33 mm Weight: 37.8 kg Glass: 2.0 mm tempered (front and rear) Frame: Anodized aluminum Connectors: T6 / MC4-EVO2 / MC4-EVO2A Cables: 360 mm / -200 mm Operating Conditions: Temperature Range: -40°C to 85°C Maximum System Voltage: 1500 V (IEC/UL) Maximum Series Fuse Rating: 35 A Temperature Coefficient (Pmax): -0.29% / °C ADDITIONAL BENEFITS Product Warranty: 12 years Linear Performance Warranty: 30 years Certifications: IEC 61215 / IEC 61730 / UL 61730 / CE / INMETRO / MCS / FSEC / UKCA / ISO 9001 / ISO 14001 / ISO 45001 High resistance to salt mist, dust, ammonia, and sand The CS7N-715TB-AG module from Canadian Solar is an ideal solution for large-scale photovoltaic projects that require maximum power, efficiency, and long-term durability.
